DATALOGGER GEOTECH TAIWAN

Technical Specification

Sensor Type	Voltage (DC,AC), Vibrating wire, 4-20mA
No of Channel	16 single ended or 8 differential.
Memory	4MB Sram for CPU usage and data storage.
Interface	Peripheral port,I/O port,RS-232 port, 3G moderm
Input Voltage	18-24VDC (from solar cell) 110-240VDC(w/AC/DC converter)
Battery package	Any 12V battery,can be powered from solar source for remote monitoring site.

Giá: liên hệ

General Information

The GT1000 is a system of multi-function datalogger which specially developed to provide straightforward yet simple solutions of data acquisition and data transmission. The system is built around datalogger Campbell Scientific CR1000, fitted with 12VDC battery package, and other optional supporting system components which are customized to specific site requirements. Typical system components are: multiplexer which can increase the number of sensors that can be monitored with the datalogger; GPRS modem to provide hi-speed wireless data transfer; and solar panel which can convert sunlight to electricity for supplying
power. Enclosed with rugged wall mounted box with IP65 grade, the GT1000 can withstand any harsh environments and bad weather.
